Installing Plywood Flooring Over Concrete

Many homes today are built over a concrete slab rather than a full basement. While a basement is nice, it’s an added expense many first-time homeowners can’t afford. Even so, that concrete slab can be problematic when they want to upgrade their home later. One way it’s a problem is for installing hardwood flooring. A plywood subfloor must be installed before hardwood flooring is installed over concrete.

Not all subfloors are the same. When discussing subflooring, people often think of lauan plywood, used as subflooring over thicker plywood, in preparation for installing a vinyl floor. In that case, the only purpose of the subflooring is to provide a smooth surface without any cracks or height irregularities at the seams.

We’re talking about a different sort of subflooring here. When installing subflooring over concrete, for example, for installing wood flooring, it is necessary to use thicker subflooring so that it can be nailed into. A minimum of 5/8″ thick plywood is recommended, with 3/4″ thick plywood considered ideal. This is the sort of plywood used as sheathing when building a house. This should be “exposure one subflooring,” meaning that it is made to withstand weather (moisture) it may be exposed during construction.

Moisture levels in concrete floors

If you’re installing plywood over an existing dry concrete floor, you shouldn’t have any problem. However, a new concrete floor contains a lot of moisture. So, you must allow it to cure for at least 60 days before even bothering to check the moisture level. The moisture level of the concrete should be down to 5.5% before attaching the plywood subflooring. Floors below grade (i.e., basement floors) may never reach this point.

If you live in an area known for flooding or your home has a history of flooding, you may want to reconsider putting in a hardwood floor. Water damages the wood and the finish on the wood floor. A hardwood floor in a basement that floods will not last.

CDX plywood, three-quarter-inch thick, is typically used for subflooring. Some people recommend using pressure-treated plywood, but that is not necessary. Even using pressure-treated plywood in a basement prone to flooding won’t help, as the hardwood floor installed won’t be pressure-treated.

Putting in a moisture barrier

A moisture barrier should always be used because moisture can damage the flooring. The specific type of moisture barrier depends on how the subflooring will be installed. There are different moisture barriers for different types of installations.

• Nail-down installation: Six–mill poly plastic sheeting or 15-lb. roofing felt should be placed on the concrete before installing the subfloor.
• Glue-down installation: Plastic and felt will not work in this application, as they would be weaker than the adhesives used to attach the flooring. Instead, a trowled or rolled liquid product is needed.
• Floating floor installation – Use a six-million-dollar poly plastic sheeting when installing a floating floor.

Please note that some plywood intended for use as underlayment may have a moisture barrier already applied to one side. In this case, no further moisture barrier is needed. These underlayments are most often used for floating floor installations.

Leveling the Concrete

Fresh concrete is supposed to be leveled and smooth when it is poured. Unfortunately, not all contractors do this well. It’s possible to have a new floor that is either not level or not plain. In either case, you’ve got high and low spots to deal with. That’s even worse if you’re working on remodeling a home, especially an older home, because chances are pretty high that you’ll have cracks and uneven places in that floor due to the home settling, even if the floor was level and plane when new.

If the concrete has uneven areas, those spots must be corrected before installing the plywood subfloor. Lumps and bumps in the concrete will prevent the plywood from sitting level. Likewise, suppose there is a seam in the concrete from two separate pours that is not smooth, even, and level. In that case, it will cause the plywood subflooring to sit unevenly, ultimately causing problems with the hardwood floor installation.

Leveling the concrete is time-consuming but not so complex that you can’t do it yourself. No specialized equipment is needed, and the materials are readily available at your local home improvement center.

Before starting anything, determine if the floor is plane and level. If you don’t have a laser level available, the easiest way is to drop marbles on the floor several times and watch what they do.

• If the marbles all roll to one side, the floor is out of level
• If the marbles congregate in one area, that is likely a low area
• If the marbles separate but go to different areas where they stop, check those areas to see if they are low spots as well
• If the marbles avoid any area, rolling away from it or around it, that’s likely a high spot

Grind down the high spots with a surface or planetary floor grinder, which you can rent, and a concrete grinding wheel, which you will probably have to buy. You can use an eight-foot contractor’s level or a string to see if you have ground it down far enough.

After eliminating the high spots, fill any cracks and holes with epoxy. If the cracks are too narrow to pour the epoxy in, widen them. You don’t want to leave any gaps. Allow the epoxy to set, then sand or grind it level. You don’t need to use the rental grinder for this; an electric hand sander will do.

Now, you’ll need to prepare the floor for using the self-leveling compound. Clean the floor thoroughly, removing grease or oil so that the leveling compound won’t stick to it. Sweep or vacuum up any dust and particles. Then, once the floor is dry, apply the latex bonding compound. This can be applied with a paintbrush and roller, just as if you were painting the floor. Allow it to dry.

Finally, you’re ready to use the self-leveling compound. Mix the compound with water according to the manufacturer’s directions, creating a slurry. It helps to use a drywall mixer in a drill and a five-gallon bucket to smooth the compound.

Pour the compound immediately, as it dries quickly. Be sure to start in the corner farthest from the door and pour as many compound buckets as needed to cover the entire floor. A special tool is used for smoothing it out, but you can use a garden rake just as well. Allow the compound a few days to dry before installing the plywood subfloor.

3 Ways of Attaching the Plywood

The plywood should be laid down in a long direction perpendicular to the grain direction of the hardwood floor. This will help prevent cracks from forming when the seam on the floor is directly over the seam on the plywood.

Do not butt the edges of the plywood together; instead, leave a 1/8″ expansion gap between the sheets to avoid buckling. Also, leave a 3/4″ gap around the edges of the floor or wherever the floor comes into contact with vertical structures, such as columns. Most of this gap will end up being covered by the baseboard.

If you are working on a remodel, you’ll probably already have drywall on the walls. As long as the drywall is mounted high enough above the existing floor to allow the plywood you are using to slip under it, you can measure that 3/4″ gap from the studs. However, if it is not that high, you will need to measure the 3/4″ from the face of the drywall.

This expansion gap is essential to prevent your floor from heaving and buckling. Putting the flooring in tight, without leaving an expansion gap, doesn’t leave anywhere for the individual sheets of plywood to expand, as they absorb moisture. The only place they have to go is to go up. As they do, they will pull fasteners through the veneers of the plywood, causing delamination, and could cause the flooring to come loose from the subflooring.

If this gap is not provided, the flooring will become so wavy that it needs to be repaired. Unfortunately, the only way to repair the floor is to remove it entirely and start over, which is a rather expensive mistake.

There are three ways of attaching plywood to the concrete floor. They are:

• Screws – Concrete screws, such as Tapcons, provide very secure fastening. This requires using a hammer drill to create a pilot hole for the Tapcons to go into and an impact driver to seat the screws. When installed, the heads of the screws must be at or below flush, as compared to the surface of the plywood. Screws should be installed every 16 inches.
• Powder Actuated Fasteners – Concrete nails, shot into the floor, work well if you install them with the heads flush or slightly below flush. They cannot be reset or driven deeper once they have been driven in by the powder-actuated tool, so run a test before using them. Like the screws, these should be 16″ apart.
• Adhesive Mastic—Newer adhesives provide an excellent alternative to traditional installation methods. When using adhesive mastic, the vapor barrier is not used; rather, a painted-on sealant is. These adhesives are expensive, making for a higher overall cost. The mastic is troweled, providing an additional moisture barrier between the plywood and the concrete.

Once the plywood subflooring is installed, check the edges for any ridges caused by the sheets of plywood not lying flat or being of different thicknesses. Any ridges found require filling with flooring-grade wood putty and then sanding to provide a smooth, continuous surface for the wood floor to be mounted to.

Floating Floors

Floating floors are becoming more common in response to HOA rules on how much noise residents can make and to provide cushioning on the floor for physical activities. In a floating floor application, two layers of plywood are stacked with offset seams; the top layer is at a 45-degree angle to the bottom.

In these cases, a pad is attached underneath the bottom layer of plywood. These pads vary, with some already attached to the underlayment. Cork is a common material, although rubber pads are also used. Pads can also be separated from the floor and laid on the concrete floor before laying the plywood down. In either case, the pads offer some flexibility to the floor, making it more comfortable to walk on and reducing the amount of noise produced when walking on the floor.

Plywood Over Battens

While not as common anymore, plywood can be installed over battens. This provides the same benefits as a floating floor and can be installed over a floor that isn’t as smooth. It is even possible to install plywood and batten subfloor over a concrete floor that isn’t level and plane. However, it would help if you had a means of verifying that you are shimming the battens correctly, such as a laser level. This method should not be used if ceramic tile is applied over the subfloor.

The battens themselves are usually 1″ x 4″ dimensional lumber. These are attached to the floor every 16′, running the room’s length. They can be attached with powder-actuated fasteners or with tapcon-type screws. In either case, the battens should be checked to verify that they are level with each other and that there are no high or low points. Low points can be shimmed, and high points planned down, if necessary.

The plywood floor is then screwed to these battens, like nailing plywood subfloors to floor joists in a multi-story home. Screws are used, rather than nails, because they only go into a 3/4″ thick board, and you don’t want them loosening up and causing a squeaky floor.

Hardwood Floors Directly Over Concrete

Although it is not common, there are some applications where hardwood floors can be installed directly over concrete without bothering to install a subfloor. This can only be done in arid places where there is little possibility of moisture coming up through the concrete and attacking the wood.

In such cases, specially engineered hardwood flooring products are used. These consist of void-free hardwood plywood, with about 1/8″ of hardwood laminated on top as the top veneer. These products are also tongue-in-groove for easier and more secure installation. A variety of different styles and finishes are available.

To make this possible, the floor must still be leveled if it is not perfectly level and plane when poured. Check the floor carefully for this, and if necessary, level the floor using the same kind of floor leveling compound mentioned above. Then, seal the floor, providing a moisture barrier.

In this case, the wood flooring is installed with a polyurethane adhesive and troweled onto the floor rather than installed with fasteners. The nails used for hardwood floors aren’t strong enough to nail into concrete. To tighten up the boards and eliminate gaps, holes are drilled, and finish nails are installed every ten boards.

Nailing these boards is done with a clamping device bolted to the floor for stability. Once bolted, a scrap piece of the tongue-and-groove flooring is used as a pad, and the hydraulic jack in the clamp is pumped up, pressing the boards together and eliminating gaps. Then, the holes are drilled, and the nails are installed. If this is causing any boards to heave off the concrete floors, you can tell because they will have a hollow sound when struck. To correct that, drill through the flooring at those locations and nail it there.

Vinyl Flooring Over Concrete – an Alternative to Wood Floors

If you need a cost-effective alternative to wood flooring, you might want to consider installing imitation wood and vinyl planks. These come in two basic styles and a variety of finishes, simulating various kinds of wood. Typically, cushioned vinyl only needs to be bonded to the floor around the perimeter, while non-cushioned flooring needs to be bonded across the whole floor. Always check the manufacturer’s instructions before installing.

When installing cushioned vinyl floor planks that are only bonded around the perimeter, the planks themselves are designed to lock together with a modified tongue-in-groove connection. The joint difference causes the planks to snap together, providing a positive lock. This is important, as vinyl flooring is thinner than wood flooring. With this sort of flooring, a special double-sided tape is applied to the concrete floor or wood subflooring all around the room’s perimeter.

In the case of non-cushioned flooring, which requires mastic across the entire flooring surface, a toothed trowel is used for applying the adhesive. Be careful not to let debris get into this adhesive, as it will cause bumps in the flooring, which could ultimately cause it to crack. In all cases, the subfloor or concrete must be cleaned before installing the vinyl flooring.

The Reverse – Concrete Over Plywood

Pouring concrete over plywood can be even more challenging than installing plywood over concrete. Nevertheless, this is not all that uncommon. It might be done to create a subfloor for ceramic tile to be installed over an existing wood subfloor or to make a concrete countertop. In either case, there are two issues to contend with rigidity and the plywood’s porosity. That porosity can cause the concrete to settle unevenly as the water soaks into the highly porous wood.

The first thing that needs to be done in this process is to ensure that the plywood floor is rigid. An additional layer of 3/4″ plywood should be installed, with screws, over the existing subfloor. Install it at the right angles of the existing, with the seams staggered to stabilize the floor.

Galvanized metal lath should then be installed over the plywood as a reinforcing material to help the concrete bond to the plywood. Screw the lath down on six-inch centers. If desired, roofing felt can be placed under the lath, between it and the plywood, as a slip sheet.

This will act as a moisture barrier, keeping the water from the concrete from soaking into the plywood and thereby helping it settle more evenly.

Not all products will work as reinforcing and attaching material between the concrete and the plywood. However, a few overlay materials have been specially designed for this. These materials have a smooth and rough side, so the smooth side can be glued to the plywood, and the rough side can give the plywood something to “bite” and adhere to.

Some of these materials also provide waterproofing or muffle sound, providing something to absorb impact and vibration, much like a floating floor.

These materials provide structural stability for the concrete so it will not fracture. If you are using a waterproof version of these materials, attaching a galvanized lath is recommended.

In this case, since the screws would pierce the moisture barrier, place a small amount of vinyl caulking on the screws before installing them to seal the hole the screw is creating.
